Hub Plus

Second-generation intelligent control panel with four communication channels, a new powerful processor, tripled RAM capacity and doubled flash memory capacity. The Hub Plus monitors the operation of all Ajax detectors and instantly alerts the owner and the security company.

Authentication to prevent forgery

Jamming detection and communication channels encryption

Tampering alarm

Uses Wi-Fi, Ethernet, WCDMA and GSM to send alarms to the Central Monitoring Station and the system’s owner

Sends a notification in case of electrical power loss and operates for up to 15 hours from battery backup

Checks the functionality of detectors at least every 12 seconds

Protects large areas

The Hub Plus is designed to protect large facilities with a great number of rooms and people. New powerful processor and increased memory capacity have expanded the capabilities of the control panel: up to 150 detectors and 50 cameras can be connected to the hub and you can add 99 users and create 25 groups for room security management.

For home and apartment

For office

For shop and cafeteria

Uses all possible alarm transmission methods

The Hub Plus is the absolute leader in field in the number of communication channels: the control panel can be connected to the Internet via Wi-Fi, Ethernet, WCDMA, and GSM. Taken together, these functions ensure ultra-stable connection and instant alarm sending to the owner’s smartphone and the Central Monitoring Station.

Alarms via calls, SMS and push notifications

Synchronized operation of all communication channels

Direct connection with central monitoring stations

Increases stability by 4 times

The Hub Plus is equipped with a GSM module with two SIM-card slots that support 2G and 3G networks. Now you can use SIM-cards of two different communications providers without any risk of communications failures. The Hub instantly switches between 2G and 3G networks. If one SIM card does not respond, the second one is activated automatically.

Improved reliability

The Hub Plus makes it possible to use redundant Internet connection by connecting the central unit to networks of two independent communications providers: the main — via Ethernet, and the backup — via Wi-Fi. If connection of one provider fails, the hub will stay connected and continue monitoring the situation at the site.

Simplifies installation and set up

The Hub Plus has a Wi-Fi module now, so it is not necessary to lay a cable for connection to the router. The control panel is ready to operate straight out the box. It is set using the mobile application, and the detectors are connected with just one click. The device can be mounted in just a few minutes using the SmartBracket mount.

Mounted in 5 minutes

Placed in any room within a Wi-Fi signal range

Mobile application for configuring and testing

Tech Specs

Classification

Maximum number of devices connected to the hub

Maximum number of users

50

Maximum number of rooms

50

Maximum number of groups

9

Mobile applications

iOS 9.1 and later
Android 4.1 and later

Communication channels

Ethernet, GSM (850/900/1800/1900 MHz)

Alarm signal

Delivery time: 0.15 s
Types of notifications: SMS message, call, push

Communication with Central Monitoring Station

Contact ID, SIA

Processor

ARM

Operating system

OS Malevich

Power supply

Mains supply: 110−240 V
Battery backup: Li-Ion 2 А⋅h
Up to 15 hours of offline operation when Ethernet is switched off

Jeweller radio technology

Communication range with detectors — up to 2,000 m in an open space
Two-way communication between devices
Operating frequencies — 868.0-868.6 MHz
Self-adjusting RF output power — up to 25 mW
Block encryption based on AES algorithm
Detector polling period — 12−300 s
Frequency hopping

SIM card support

Micro SIM 2G

Operating temperature range

-10°С to +40°С

Anti-sabotage

Protection against fraud
Jamming detection
Tamper-resistant

Video surveillance

Up to 10 cameras or DVRs

Remote set up

+

Dimensions

163x163x36 mm

Weight

350g

Certification

Grade 2, CE

Warranty

Replacement and repair within 24 months of the date of sale. Batteries are not covered under warranty.

MotionCam detectors support

The radio channel central unit with GSM and Ethernet modules

100

No
